USB Drivers

USB Driver Installation Procedures:

1. Install this base driver for Windows XP/Vista/7/8/8.1 first; and

2. Install the upgrade driver according to your Windows version as shown in RED color above.

Application Software

of

PRO2 ECU

for

Malaysia Distributor

MOTOTAN PARTS SDN. BHD.

_

1. Lastest verion .

Firmware upgrade is NOT required to enable the above function.

1. Support a/A/s/S/z/Z/x/X hot-keys for instant increasing and decreasing values in 3D fuel and spark angle tables;

2. Support i/I hot-keys for bilinear interpolation functions.

Firmware upgrade is NOT required to enable the above function.

1. Support YAMAHA SRL115;

2. Support customized wideband A/F sensor setting;

3. Simplify software menu and tuning style with new coloured 3D table display.

Both firmware upgrade and map file uploading are required to enable the new function.

If previously saved map file is not available, please use this software to download map file and upload again.

Map 1 ~ 3 should be uploaded separately to enable the new function completely.

1. Support new PRO2 single-map version ECUs;

2. Support second fuel injector and NOS solenoid relay conrtrol for high-end ECUs.

Both firmware upgrade and map file uploading are required to enable the new function.

If previously saved map file is not available, please use this software to download map file and upload again.

Map 1 ~ 3 should be uploaded separately to enable the new function completely.

1. Support new F2+ ECU for HONDA CRF150 2018~2020;

2. Add a new function to clear password and reset maps if ECU is password protected. While the ECU is connected to software via USB cable and ignition key switch is turned on, the top-right cornor of software will have a "LOCK" icon to indicate the ECU is password protected. Use your mouse to click on the "LOCK" icon, software will ask you whether you want to clear the password and reset maps.

Firmware upgrade is NOT required to enable the above function.

1. Support new programmable dwell time (ignition coil charge time) function;

2. Support new hot-key hints;

3. Support new FI diagnosis code with descriptions;

4. Bug fix of TPS % display error after map downloading; and

5. Support new function of disabling unrelated control fields for different ISC mode settings.

Both firmware upgrade and map file uploading are required to enable the new function.

If previously saved map file is not available, please use this software to download map file and upload again.

Map 1 ~ 3 should be uploaded separately to enable the new function completely.

1. Support new F2+ ECU for YAMAHA Y15 v2;

2. Support new F2+ ECU for BENELLI RFS150; and

3. Update product logo to KZR(TM).

Add new functions of interpolation (linear and bilinear) for both effective fuel width and ignition advance angle 3D tables.

Firmware upgrade is NOT required to enable the above function.

Bug Fix - Solve the display problem of gear position compensation page.

Firmware upgrade is NOT required to enable the above bug fix.

After software is installed, please upgrade ECU firmware also to enable the following new functions:

1. Add new functions to support backfire while shifting gears in "Quick Shifter" settings (New F2+ enhanced version only);

2. Fix bug of uploading to and downloading from both map areas 1 and 2; and

3. Support new F2+ ECU for SYM VF3i 185cc.

This 1.2.1 software can support both original F2 ECU and new F2+ enhanced version ECU. After upgrading firmware of the origin F2 ECU, new functions as shown above except the functions dedicated for F2+ enhanced version ECU can be supported.

File name prefix of the firmware:

"F2-" : original F2 ECU

"F2+" : new F2+ enhanced version ECU

After software is installed, please upgrade ECU firmware also to enable the following new functions:

1. Support new "Launch Control" related functions;

2. Support new "Mis-Fire / Anti-Lag System " related functions;

3. Support new "Quick Shifter" related functions (New F2+ enhanced version only);

4. Support new "MAP Sensor Setting" related functions;

5. Support new "Flywheel Type / TDC Angle / Crankshaft Sensor" related setting functions;

6. Support new "ENGT Sensor" related setting functions;

7. Support new "AIRT Sensor" related setting functions;

8. Support new "Instant Map Select Switch" related setting functions (New F2+ enhanced version only); and

9. Open three map areas (1 / 2 / 3) to users for storing different riding modes.

This 1.1.0 software can support both original F2 ECU and new F2+ enhanced version ECU. After upgrading firmware of the origin F2 ECU, new functions as shown above except the functions dedicated for F2+ enhanced version ECU can be supported.

File name prefix of the firmware:

"F2-" : original F2 ECU

"F2+" : new F2+ enhanced version ECU

New feature of software 1.0.1 - Fix the display problem of disappeared TPS 100% column in effective fuel width, ignition advance angle and wideband A/F log tables for some graphic display cards.

Firmware upgrade is NOT required to enable the above new feature.

New feature of software 1.0.0 - while running under the EZ dynamic tracking mode, the last referenced cell will be marked in RED color while the past referenced cells were marked in light yellow color.

No firmware upgrade is required to enable the above new feature.

After software is installed, please upgrade ECU firmware also to enable the following new functions:

1. Support new programmable "Shift Indication Light";

2. Support new "On Road A/F Logging" mode; and

3. Support fuel table / ignition table editing while running under the EZ dynamic tracking mode.

Introduction to EZECU® - KZR ECU Products, Software, and Basic Tuning - Part 1: EZECU® Products and GO2™ Wideband A/F Controller

Left: Traditional Chinese / Right: English

Introduction to EZECU® - KZR ECU Products, Software, and Basic Tuning - Part 2: Operating EZECU® Software

Left: Traditional Chinese / Right: English

Introduction to EZECU® - KZR ECU Products, Software, and Basic Tuning - Part 3: EZECU® Basic Tuning Procedures

Left: Traditional Chinese / Right: English
